| Print Method |
Direct Thermal |
| Print Speed |
Up to 4 ips (102 mm/sec - Label) |
| |
Up to 3 ips (76 mm/sec - Linerless) |
| |
12.5% pattern |
| Print Resolution |
203 dpi |
| |
|
| Print Width |
Up to 104 mm |
| Sensing |
Paper End |
| Gap |
| Black Mark |
| Paper Cover Open |
| Media Characteristics |
|
| Media Type |
Label, Linerless (Optional) |
| Media Width |
112 mm / 105 mm (Optional) |
| Media Roll Diameter |
Up to 56 mm |
| Media Thickness |
0.07 ~ 0.15 mm |
| Supply Method |
Easy Paper Loading |
| Physical Characteristics |
|
| Dimensions (WxDxH) |
143.0 x 138 x 66 mm |
| |
(5.63 x 5.44 x 2.60 inch) |
| Weight |
Including battery: 530 g (1.17 Ibs.) |
| |
Paper : 242 g (0.53 lbs.) |
| Electrical |
7.3 V Li-ion, 2600 mAh, |
| |
Rechargeable Charging time: Up to 4.0 hrs |
| |
EnergyStar Certified |
| Performance Characteristics |
|
| Memory |
128 MB SDRAM, 256 MB Flash |
| |
256 MB SDRAM, 512 MB Flash (Optional) |
| Interface |
Standard: USB V2.0 HS + Serial |
| |
Optional: USB V2.0 HS + Serial + Bluetooth¹ / |
| |
WLAN² |
| |
Bluetooth¹: V4.1 Classic & LE |
| |
WLAN²: 802.11a/b/g/n (Infrastructure, Ad-hoc, |
| |
Wi-Fi Direct, SoftAP) - WEP40/104, |
| |
WPA1/2(PSK, EAP) |
| |
* Easy Bluetooth Pairing™ via NFC |
| Software |
SLCS, BPL-Z™ (ZPLII), BPL-C™ (CPCL) |
| |
Driver / Utility |
| |
Windows Driver (Europlus / Seagull), |
| |
Linux / Mac CUPS Driver, Virtual COM USB Driver, |
| |
Utility Program, LabelArtist-II™, Bartender UL, |
| |
OPOS / JPOS Driver |
| |
SDK / Plugin |
| |
Android / iOS / Windows SDK, Linux SDK, |
| |
Chrome SDK, Xamarin SDK, Cordova Plugin |
| Application |
Label Artist™ Mobile (Android, iOS), |
| |
mPrint App (iOS) |
| Environment Characteristics |
|
| Temperature |
Operating: -15 ~ 50℃ (5 ~ 122℉) |
| |
Storage: -30 ~ 70℃ (-22 ~ 158℉) |
| Humidity |
Operating: 10 ~ 80% RH |
| Sealing |
IP54 |
| Drop Rate |
1.8 m (6 ft.) |
