| Resolution |
8 dots/mm (203 DPI) |
| Printing method |
Thermal Transfer & Direct Thermal |
| Max. print speed |
254 mm (10”)/second |
| Max. print width |
108 mm (4.25") |
| Max. print length 25,400 mm (1000") |
25,400 mm (1000") |
| Enclosure |
Die-cast based print mechanism/Metal cover with large clear media view window |
| Physical dimension |
248 mm (W) x 274 mm (H) x 436 mm (D) |
| |
9.76” (W) x 10.79” (H) x 17.17” (D) |
| Weight |
9.2 kg (20.28 lbs) |
| Label roll capacity |
203.2 mm (8“) O.D. |
| Ribbon |
450 m long, max. O.D. 81.3 mm, 1“ core (ink coated outside or inside) |
| Ribbon width |
40 mm ~ 110 mm (1.6” ~ 4.3”) |
| Processor |
32-bit RISC CPU |
| Memory |
128 MB Flash memory |
| |
128 MB SDRAM |
| Interface |
• RS-232 |
| |
• USB 2.0 |
| |
• Internal Ethernet, 10/100 Mbps |
| |
• USB host, for scanner or PC keyboard |
| |
• GPIO (dealer option) |
| |
• Internal Bluetooth 4.2 (dealer option) |
| |
• Slot-in 802.11 a/b/g/n wireless (dealer option) |
| |
|
| Power |
Internal universal switching power supply |
| |
• Input: AC 100-240V, 2.0A, 50-60Hz |
| |
• Output: DC 24V, 3.75A, 90W |
| |
|
| LED/LCD • 3.5” touch HVGA color LCD |
• 1 status indicator |
| |
Operation switch, |
| |
button • 6 buttons (Menu, Pause/Feed, Up, Down, Left, Right) |
| |
|
| Sensors |
• Gap transmissive sensor (position adjustable) |
| |
• Black mark reflective sensor (position adjustable) |
| |
• Ribbon encoder sensor |
| |
• Ribbon end sensor |
| |
• Head open sensor |
| |
|
| Real time clock Standard |
|
| Internal fonts |
8 alpha-numeric bitmap fonts |
| |
• Monotype Imaging true type font engine with one CG Triumvirate Bold Condensed scalable font |
| Bar code |
• 1D bar code |
| |
Code 39, Code 93, Code128UCC, Code128 subsets A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128, |
| |
UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11, |
| |
China Post |
| |
• 2D bar code |
| |
PDF-417, Maxicode, DataMatrix, QR code, Aztec |
| |
|
| Font and barcode rotation |
0, 90, 180, 270 degree |
| |
|
| Printer language |
TSPL-EZD (Compatible to EPL, ZPL, ZPL II, DPL) |
| Media type |
Continuous, die-cut, black mark, fan-fold, notched (outside wound) |
| Media width |
20 ~ 120 mm (0.8” ~ 4.7”) |
| Media thickness |
0.06 ~ 0.28 mm (2.36 ~ 11 mil) |
| Media core diameter |
25.4 mm ~ 76.2 mm (1” ~ 3”) |
| Label length |
5 ~ 25,400 mm |
| |
(0.2" ~ 1000") |
| |
5 ~ 11,430 mm |
| |
(0.2" ~ 1000") |
| Environment condition Operation |
5 ~ 40 C, 25 ~ 85% non-condensing |
| Storage |
-40 ~ 60 C, 10 ~ 90% non-condensing |
| Safety regulation |
FCC Class A, CE Class A, RCM Class A, cTUVus, CCC, BIS, T V, KC, BSMI, EAC, ENERGY STAR |
| Environmental concern |
Comply with RoHS, WEEE |
| |
|
| Accessories |
• Windows labeling software CD disk |
| |
• Quick start guide |
| |
• USB cable |
| |
• Power cord |
| |
Limited warranty |
| |
• Printer: 2 years |
| |
• Print head: 25 km (1 million inches) or 12 months which comes first |
| |
• Platen: 50 km (2 million inches) or 12 months which comes first |
| |
Dealer options |
| |
• Peel-off kit |
| |
• 5” OD internal rewinding kit |
| |
• Regular guillotine cutter (full cut) |
| |
• GPIO |
| |
• 802.11 a/b/g/n wireless module (for device without slot-in housing)* |
| |
• Internal Bluetooth 4.2** |
| |
